XL-MP110H/MP110E
1 – 1
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
CHAPTER 1. GENERAL DESCRIPTION
[1] SAFETY PRECAUTION FOR SERVICE MANUAL
Precaution to be taken when replacing and servicing the Laser Pickup.
The AEL (Accessible Emission Level) of Laser Power Output for this model is specified to be lower than Class 1 Requirements. However, the follow-
ing precautions must be observed during servicing to protect your eyes against exposure to the Laser beam.
1) When the cabinet has been removed, the power is turned on without a compact disc, and the Pickup is on a position outer than the lead-in posi-
tion, the Laser will light for several seconds to detect a disc. Do not look into the Pickup Lens.
2) The Laser Power Output of the Pickup inside the unit and replacement service parts have already been adjusted prior to shipping.
3) No adjustment to the Laser Power should be attempted when replacing or servicing the Pickup.
4) Under no circumstances look directly into the Pickup Lens at any time.
5) CAUTION - Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation
exposure.
[2] SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER TO THE OPERATION MANUAL.
XL-MP110H
General
Amplifier
CD player
Tuner
Cassette deck
Speaker
Power source AC230V,50Hz
Power
consumption
Power on:100 W
Power stand-by: 0.6 W(*)
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 307 mm (12")
Weight 6.1 kg (13.4 lbs.)
( * )This power consumption value is obtained when the demonstra-
tion mode is cancelled in the power stand-by mode. Refer to
page 9 to cancel the demonstration mode.
Output power PMPO: 364 W (total)
MPO: 182 W (91 W + 91 W) (DIN 45 324)
RMS: 100 W (50W+50W)(DIN 45 324)
RMS: 68 W (38 W + 38 W) (DIN 45 500)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Subwoofer pre-out (audio signal):
200mV/10kohmsat70Hz
Input terminals Video/Auxiliary (audio signal):
500mV/47kohms
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 2-way type speaker system
5cm(2")tweeter
13 cm (5-1/8") woofer
Maximum input
power
100 W
Rated input power 50 W
Impedance 6ohms
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 205 mm (8-1/16")
Weight 2.4 kg (5.3 lbs.)/each
■
■
■
■
■
■
To Next Page
