Sharp XL-MP110H Service Manual

XL-MP110H/MP110E
1 – 2
XL-MP110E
General
Amplifier
Tuner
Cassette deck
Speaker
Power source AC 230 - 240 V, 50 Hz
Power
consumption
100 W
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 307 mm (12")
Weight 6.1 kg (13.4 lbs.)
Output power
MPO: 182 W (91 W + 91 W) (10 % T.H.D.)
RMS: 100 W (50 W + 50 W) (10 % T.H.D.)
RMS: 76 W (38 W + 38 W) (0.9 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Subwoofer pre-out (audio signal):
200mV/10kohmsat70Hz
Input terminals Video/Auxiliary (audio signal):
500mV/47kohms
Frequency range FM: 87.50 - 108.00 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
5 cm (2") tweeter
13 cm (5-1/8") woofer
Maximum input
power
100 W
Rated input power 50 W
Impedance 6 ohms
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 205 mm (8-1/16")
Weight 2.4 kg (5.3 lbs.)/each
■■
■
■
■
■
CD player
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Specifications for this model are subject to change without prior
notice.

Sharp XL-MP110H Specifications
