E-40
ENGLISH
8
XL-MP110H
References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
General
Amplifier
CD player
Tuner
Cassette deck
Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on:100 W
Power stand-by: 0.6 W(*)
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 307 mm (12")
Weight 6.1 kg (13.4 lbs.)
( * )This power consumption value is obtained when the demonstra-
tion mode is cancelled in the power stand-by mode. Refer to
page 9 to cancel the demonstration mode.
Output power PMPO: 364 W (total)
MPO: 182 W (91 W + 91 W) (DIN 45 324)
RMS: 100 W (50 W + 50 W) (DIN 45 324)
RMS: 76 W (38 W + 38 W) (DIN 45 500)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Subwoofer pre-out (audio signal):
200 mV/10 k ohms at 70 Hz
Input terminals Video/Auxiliary (audio signal):
500 mV/47 k ohms
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 2-way type speaker system
5 cm (2") tweeter
13 cm (5-1/8") woofer
Maximum input
power
100 W
Rated input power 50 W
Impedance 6 ohms
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 205 mm (8-1/16")
Weight 2.4 kg (5.3 lbs.)/each
