Sharp XR-10X-L User Manual

XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
13
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R9102 VRS-CY1JF184FY AA J Resistor 180k 1/16W Metal Oxide
R9103 VRN-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Film
R9301 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9303 VRS-CJ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9304 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9305 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
SC9101 QSOCZA102WJZZQ AW N J Socket 142Pin(to MAIN PWB)
TH9102 VHH103KT161-1Y AE J Thermistor
[4] DUNTKD141WEF4 (PHOTO SENSOR Unit)
C1101 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1102 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
IC1101 VHiLM393A//-1Y AL J IC LM393APSR
IC1102 VHPGP2S40//-1S AK N J IC PHOTODIODE
P1101 QPLGN0363TAZZY AC J Plug 3Pin(CW)
R1101 VRS-TQ2EF121JY AA J Resistor 120 1/4W Metal Oxide
R1102 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1103 VRS-CY1JF153JY AA J Resistor 15k 1/16W Metal Oxide
R1104 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
N QCNW-C221WJQZ AF J Connecting Cord
[5] DUNTKD147WEF6 (BALLAST POWER Unit)
C702 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C703 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C704 RC-EZA572WJZZ AW J Capacitor 330 420V Electrolytic
C705 VCKYTV1EB474KY AC J Capacitor 0.47 25V Ceramic
C706 VCKYCY1EB333KY AA J Capacitor 0.033 25V Ceramic
!
C707 RC-FZA026WJZZ AE J Capacitor 0.47 50V Metallized Plastic Film
C708 VCKYCY1HB222KY AA J Capacitor 2200p 50V Ceramic
C709 RC-KZA271WJZZ AC J Capacitor 470 2kV Ceramic
C710 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Ceramic
!
C711 RC-KZ0105GEZZ AD J Capacitor 2200p 250V Ceramic
!
C712 RC-KZ0105GEZZ AD J Capacitor 2200p 250V Ceramic
C713 VCKYTQ1HB224KY AC J Capacitor 0.22 50V Ceramic
C714 RC-FZA124WJZZ AG J Capacitor 2.2 450V Metallized Plastic Film
!
C715 RC-FZA026WJZZ AE J Capacitor 0.47 50V Metallized Plastic Film
C716 VCKYTV1EB104KY AB J Capacitor 0.1 25V Ceramic
C717 VCKYTV1EB104KY AB J Capacitor 0.1 25V Ceramic
C718 VCKYTV1HB103KY AA J Capacitor 0.01 50V Ceramic
C720 VCEA4A1VN476M+ AC J Capacitor 47 35V Electrolytic
C721 VCEA4A1VN106M+ AC J Capacitor 10 35V Electrolytic
C722 VCKYTV1HB222KY AA J Capacitor 2200p 50V Ceramic
C723 VCKYTV1HB471KY AA J Capacitor 470p 50V Ceramic
C724 VCKYTV1HB103KY AA J Capacitor 0.01 50V Ceramic
C725 VCEA4A1HN105M+ AB J Capacitor 1 50V Electrolytic
C726 RC-KZA050WJZZ AD J Capacitor 450p 50V Ceramic
C727 VCEA4A1VN107M+ AC J Capacitor 100 35V Electrolytic
C728 RC-FZ0010TAZZ AC J Capacitor 0.01 630V Metallized Plastic Film
!
C730 RC-KZ0105GEZZ AD J Capacitor 2200p 250V Ceramic
!
C731 RC-KZ0105GEZZ AD J Capacitor 2200p 250V Ceramic
C732 RC-EZ1208CEZZ AD J Capacitor 2200 25V Electrolytic
C733 RC-KZ0384CEZZ+ AC J Capacitor 1000p 50V Ceramic
C734 RC-KZ0384CEZZ+ AC J Capacitor 1000p 50V Ceramic
!
C735 RC-KZ0105GEZZ AD J Capacitor 2200p 250V Ceramic
C736 VCKYTV1EB104KY AB J Capacitor 0.1 25V Ceramic
C737 RC-EZ1241CEZZ AE J Capacitor 2200 25V Electrolytic
C738 VCEA4A1VN476M+ AC J Capacitor 47 35V Electrolytic
C739 RC-KZA111WJZZY AC J Capacitor 1 25V Ceramic
C740 RC-FZA126WJZZ AE J Capacitor 0.1 450V Metallized Plastic Film
C901 RC-FZA215WJZZ AH J Capacitor 1.8 450V Metallized Plastic Film
C902 RC-KZA448WJZZY AD N J Capacitor 220p 1kV Ceramic
C904 RC-KZA111WJZZY AC J Capacitor 1 25V Ceramic
C909 RC-KZA449WJZZY AD N J Capacitor 330p 1kV Ceramic
C910 RC-KZA449WJZZY AD N J Capacitor 330p 1kV Ceramic
C911 RC-FZA123WJZZ AF J Capacitor 1 450V Metallized Plastic Film
C912 RC-KZA437WJZZY AD N J Capacitor 1000p 630V Ceramic
C913 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C914 RC-FZA126WJZZ AE J Capacitor 0.1 450V Metallized Plastic Film
C915 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Ceramic
C916 RC-FZA126WJZZ AE J Capacitor 0.1 450V Metallized Plastic Film
C917 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Ceramic
C919 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C920 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Ceramic
C921 VCKYCY1EB473KY AA J Capacitor 0.047 25V Ceramic
C922 RC-KZA448WJZZY AD N J Capacitor 220p 1kV Ceramic
C923 RC-KZA448WJZZY AD N J Capacitor 220p 1kV Ceramic
!
CN901 QCNW-E997WJQZ AV N J Connecting Cord
!
D701 VHDD10XB60H-1 AL N J Diode D10XB60H-7101
D702 VHD1SS355//-1Y AB J Diode 1SS355TE-17
D703 RH-DXA073WJZZ AM N J Diode YG97S6R
D704 VHD1SS355//-1Y AB J Diode 1SS355TE-17
D705 VHDLi114+++-1Y AC J Diode LI114
D706 VHDRB160M40-1Y AC J Diode RB160M-40TR
D707 VHDRB160M40-1Y AC J Diode RB160M-40TR
[3] DUNTKD140WEF0 (DMD Unit)
