Sharp XR-10X-L User Manual

XR-10X-L/XR-10S-L/XG-MB50X-L/XR-11XC-L/XR-HB007X-L
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
D708 VHDD1FL20U/-1Y AC J Diode D1FL20U
D709 RH-DX0066GEZZY AC J Diode AL01ZV1
D710 RH-EX1294CEZZY AB J Zener Diode HZU27BTRF-E
D711 RH-DX0066GEZZY AC J Diode AL01ZV1
D712 RH-DX0066GEZZY AC J Diode AL01ZV1
D713 VHDD1FL20U/-1Y AC J Diode D1FL20U
D714 RH-DXA070WJZZY AE N J Diode SARS01V1
!
D715 RH-FXA003WJZZ AD J Diode PC123Y82
!
D716 RH-FXA003WJZZ AD J Diode PC123Y82
D717 RH-DX0459CEZZ AE J Diode D5S4M
D718 RH-DX0469CEZZ AF J Diode D3S6M
D722 VHD1SS355//-1Y AB J Diode 1SS355TE-17
D907 VHSG1VB22C+-1 AK J Diode SI.Control Rectifier
D908 RH-DXA074WJZZ AH J Diode SF10L60U-7100
D909 VHDU1JU44//-1Y AE J Diode U1JU44(TE12R,Q)
D910 RH-DXA062WJZZY AE J Diode SHV-04V6
D911 VHDFMQG2FLS-1 AN N J Diode FMQ-G2FLS
D913 VHDFMQG2FLS-1 AN N J Diode FMQ-G2FLS
D914 RH-DXA062WJZZY AE J Diode SHV-04V6
D915 VHDRB160M40-1Y AC J Diode RB160M-40TR
E701 LANGQA017WJFW AG J Fixing Metal
!
F701 QFS-CA010WJZZ AF J Fuse T6.3AH/AC250V
!
F705 QFS-TA005WJZZ AG J Thermal Fuse 127°C
FB701 RBLN-0094CEZZY AC J Ferrite Bead BLN-0094CE
FB702 RBLN-0094CEZZY AC J Ferrite Bead BLN-0094CE
FB704 RBLN-A007WJZZY AC J Ferrite Bead BLN-A007WJ
FB705 RBLN-A007WJZZY AC J Ferrite Bead BLN-A007WJ
FB706 RBLN-A007WJZZY AC J Ferrite Bead BLN-A007WJ
FB707 RBLN-0020CEZZ+ AB J Ferrite Bead BLN-0020CE
FB903 RBLN-A007WJZZY AC J Ferrite Bead BLN-A007WJ
FH701 QFSHD1013CEZZ+ AC J Fuse Holder
FH702 QFSHD1014CEZZ+ AC J Fuse Holder
IC702 VHiTA78M12S-1 AG J IC TA78M12S(Q)
IC703 VHiSTRW67652E AL J IC STR-W6765N
IC704 VHiHA17431U-1Y AE J IC HA17431UA-TL-E
IC902 VHiFA5501AN-1Y AQ N J IC FA55501AN-D1-TE1
L701 RCiLPA137WJZZ AF J Coil
!
L702 RCiLFA178WJZZ AK J Coil
!
L703 RCiLFA178WJZZ AK J Coil
L705 RCiLPA546WJZZ AH J Coil
L901 RCiLCA126WJZZ AQ N J Coil
L902 RCiLPA475WJZZ AK J Coil
LUG701 QLUGHA002WJZZ AB J Lug
LUG702 QLUGHA002WJZZ AB J Lug
!
P701 QPLGAA004WJZZ AH J AC Plug
!
P702 QPLGN0269GEZZ AB J Plug 2Pin(BA)
P704 QCNCMA114WJZZ AF J Connector 14Pin
Q702 VS2SK3451++-1 AS N J Transistor 2SK3451-01MR-F119
Q704 VS2SK3451++-1 AS N J Transistor 2SK3451-01MR-F119
Q705 VS2SA1797Q+-1Y AD J Transistor 2SA1797 T100 Q
Q706 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q901 VS2SK2699++-1 AR J Transistor 2SK2699(SHARP,F)
Q904 VS2SA2056++-1Y AE J Transistor 2SA2056(TE85L,F)
Q905 VS2SK3525++-1 AM J Transistor 2SK3525-01MR-F119
Q906 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q907 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
!
R701 RR-HZ0119CEZZY AC J High Voltage High Resistor
R702 VRS-CY1JF153FY AA J Resistor 15k 1/16W Metal Oxide
R703 VRS-TQ2BD474FY AA J Resistor 470k 1/8W Metal Oxide
R704 VRS-TQ2BD474FY AA J Resistor 470k 1/8W Metal Oxide
R705 VRS-TQ2BD394FY AA J Resistor 390k 1/8W Metal Oxide
R706 VRN-TV1JD684DY AB N J Resistor 680k 1/16W Metal Film
R707 VRN-TV1JD564DY AB N J Resistor 560k 1/16W Metal Film
R708 VRN-TV1JD564DY AB N J Resistor 560k 1/16W Metal Film
R710 VRN-CY1JF133DY AB J Resistor 13k 1/16W Metal Film
R711 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R714 VRD-RM2HD102JY AA J Resistor 1k 1/2W Carbon
R715 VRS-CY1JF820FY AA J Resistor 82 1/16W Metal Oxide
R716 VRS-SV2HC100JY AB J Resistor 10 1/2W Metal Oxide
R717 RMPTKA001WJZZ AH J Packaged circuit
R718 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R719 VRD-RM2HD563JY AA J Resistor 56k 1/2W Carbon
R720 VRD-RM2HD563JY AA J Resistor 56k 1/2W Carbon
R721 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R722 VRD-RM2HD563JY AA J Resistor 56k 1/2W Carbon
R724 RR-WZA012WJZZ AE J Resistor 0.15 5W Resistor Wire
R725 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R727 RR-WZA012WJZZ AE J Resistor 0.15 5W Resistor Wire
R728 VRS-CY1JF183JY AA J Resistor 18k 1/16W Metal Oxide
R730 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R731 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R733 VRS-TQ2BD153JY AA J Resistor 15k 1/8W Metal Oxide
R734 VRD-RM2HD221JY AA J Resistor 220 1/2W Carbon
R735 VRS-TQ2BD101JY AA J Resistor 100 1/8W Metal Oxide
[5] DUNTKD147WEF6 (BALLAST POWER Unit)
