Sharper Image SR410 - Assembly Guide; Assembly Step 1: Base Connection

Step 1
•Attach the Rear Base (26) to the Main Base (1) with Bolt (38),
Washer (46) and Nut (41). (See Figure A.)
•Remove Sleeve Cover (29) from the Main Base (1) and connect
the Sensor Wire (31) to the Contact Wire (28). (See Figures B
and C.)
Figure A. Figure C.
Figure B.
