Shaver HD-8-S - Ram

45
Driver Assembly
SM-0011S-DRC - Ram Assembly, HD-8 Driver Stabilized
SM-1011S-DRC - Ram Assembly, HD-10 Driver Stabilized (SHOWN)
SM-1012S-DRC - Ram Assembly, SHD-10 Driver Springless
Item
Qty.
SM-0011S-DRC
HD-8
Qty.
SM-1011S-DRC
HD-10 (Shown)
Qty.
SM-1012S-DRC
SHD-10 Springless
Part No.
Description
1
1
-
-
SM-0011-DRO
Ram Assembly, Driving, Only, HD-8
-
1
-
SM-1011-DRO
Ram Assembly, Driving, Only, HD-10 (Shown)
-
-
1
SM-1012-DRO
Ram Assembly, Driving, Only, SHD-10 Springless
2
1
-
-
SM-00412S
Carriage Assembly, HD-8 Stabilized
-
1
1
SM-10412S
Carriage Assembly, HD-10 Stabilized (Shown)
3
1
-
NA
SM-0011-SA
Spring Assembly, HD-8
-
1
NA
SM-1011-SA
Spring Assembly, HD-10 (Shown)
4
-
1
NA
SM-1011-SBU
Bracket, Upper, HD-10 Spring
5
1
-
-
SM-0263-S
Cylinder Assembly, Complete HD-8
-
1
1
SM-1026-S
Cylinder Assembly, Complete HD-10/12 (Shown)
6
1
-
-
SM-0267
Locknut, Piston, HD-8
-
1
1
SM-10267
Locknut, Piston, 1-8 Nylon (Shown)
7
4*
4*
6*
SM-00512R
Block, Nyrim
7A
SM-00510
Roller, UHMW, Driver
-
*
*
*
SM-00512
Nyrim Block – Pack of 4 (Not Shown)
SM-00510-4
UHMW Rollers – Pack of 4 (Not Shown)
8
1
-
-
SM-0041-RLB
Bracket Assembly, Road Lock HD-8
-
1
1
SM-1041-RLB
Plate Assembly, Road Lock HD-10 (Shown)
9
1
1
1
SM-1041-RLC
Clip, Road Lock
10
1
1
1
SM-1041-RLP
Pin, Road Lock
11
AR
AR
AR
SM-0933
Shim, 18 Ga. (.0478”) Driver (Shown)
AR
AR
AR
SM-0934
Shim, 14 Ga. (.0747”) Driver
AR
AR
AR
SM-0935
Shim, 10 Ga. (.1345”) Driver
12
1
-
-
300166
Washer, Lock 3/4"
-
1
1
300112
Washer, Lock 1"(Shown)
13
2
-
-
300194
Bolt, Tap 3/8-16 x 2 Hex Head Gr5 Zn
-
2
2
300113
Bolt, Tap 7/16-14 x 2-1/2 Hex Head Gr5 Zn (Shown)
14
2
-
-
300180
Hex Nut, Heavy Pattern 3/8-16 Zn
-
2
2
300115
Hex Nut, Heavy Pattern 7/16-14 Zn (Shown)
15
2
-
-
300181
Nut, Cone 3/8-16 Lock Zn
-
2
2
300356
Nut, Cone 7/16-14 Lock Zn (Shown)
16
NA
2
NA
300181
Nut, Cone 3/8-16 Lock Zn
17
NA
2
NA
300189
Bolt, Tap 3/8-16 x 1 Hex Head Gr5 Zn
