Shaver HD-8-S - Specifications

9
Specifications
DESCRIPTION
HD-8-S & HD-8-H-S
HD-10-S & HD-10-H-S
Approximate Height
1
88 in (223.5 cm) collapsed
133 in (337.8 cm) extended
100 in (254 cm) collapsed
148 in (376 cm) extended
Approximate Width
2
30 in (76.2 cm)
44 in (111.8 cm)
Approximate Depth
2
28 in (71.1 cm)
33 in (88.8 cm)
Shipping Weight
694 lbs. (315 kg) manual base 714 lbs. (324 kg)
hydraulic base
694 lbs. (315 kg) manual base 714 lbs. (324 kg)
hydraulic base
Effective Weight of
Driving Ram
360 lbs. (163.3 kg) Spring Powered
725 lbs. (329 kg) Spring Powered
Impact (at full stroke)
30,000 lbs. (13,607.8 kg)
71,500 lbs. (32,432 kg)
Tilt Front/Back
15°/15°
15°/15°
Tilt Side/Side
15°/15°
15°/15°
Guide Blocks or
Rollers
4 (2 per side)
4 (2 per side)
Mounting Options
Tractor (rear/front) and skid steer Three-Point Hitch
Category I and II
Tractor (rear/front) and skid steer Three-Point Hitch
Category II and III
Hydraulic
Requirements
3 - 4 GPM at 1500 PSI (11.3-15.1 LPM at 10,342
kPa)
12 GPM at 1500 PSI (45 LPM at 10,342 kPa)
Post Size Maximums
Width 7-1/8 in (18.1 cm)
Length 10 ft (3.0 m)
Width 8-3/4 in (22.2 cm)
Length 10 ft (3.0 m)
1
Driving ram and main carriage channel. Overall height will vary, depending on mounting position and tractor.
2
With storage legs attached to three-point hitch weldment.
DESCRIPTION
SHD-10 Springless
HD-12-H-S
Approximate Height
1
100 in (254 cm) collapsed
158 in (400 cm) extended
100 in (254 cm) collapsed
148 in (376 cm) extended
Approximate Width
2
44 in (111.8 cm)
44 in (111.8 cm)
Approximate Depth
2
33 in (88.8 cm)
38 in (96.5 cm)
Shipping Weight
1074 lbs. (487 kg)
975 lbs. (442 kg)
Effective Weight of
Driving Ram
803 lbs. (364.3 kg)
1,100 lbs. (499 kg) Spring Powered
Impact (at full stroke)
95,000 lbs. (43,091 kg)
100,000 lbs. (45,359 kg)
Tilt Front/Back
20°/20°
20°/20°
Tilt Side/Side
25°/25°
25°/25°
Guide Blocks or
Rollers
6 (3 per side)
6 (3 per side)
Mounting Options
Tractor (rear/front) and skid steer Three-Point Hitch
Category II and III
Tractor (rear) and skid steer Category II and III
Hydraulic
Requirements
12 GPM at 1500 PSI (45 LPM at 10,342 kPa)
15 GPM at 2000 PSI (45 LPM at 13,790 kPa)
Post Size Maximums
Width 8-3/4 in (22.2 cm)
Length 10 ft (3.0 m)
Width 10-7/8 in (27.6 cm)
Length 10 ft (3.0 m)
1
Driving ram and main carriage channel. Overall height will vary, depending on mounting position and tractor.
2
With storage legs attached to three-point hitch weldment.
