Shaver HD-8-S - Page 47

47
Driver Assembly
SM-1211S-DRC - Ram Assembly, HD-12 Driver Stabilize
Item
Qty.
Part No.
Description
1
1
SM-1211-DRO
Ram Assembly, Driving, Only, HD-12
2
1
SM-12412S
Carriage Assembly, HD-12 Stabilized
3
1
SM-1211-DRSA
Spring Assembly, HD-12
4
1
SM-1211-SBU
Bracket, Upper, HD-12 Spring
5
1
SM-1026-S
Cylinder Assembly, Complete HD-10/12
6
1
SM-10267
Locknut, Piston, 1-8 Nylon
7
6*
SM-00512R
Block, Nyrim
-
-
SM-00512
Nyrim Block – Pack of 4 (Not Shown)
8
1
SM-1241-RLBC
Bracket Weldment, Road Lock HD-12
9
1
SM-1041-RLC
Clip, Road Lock
10
1
SM-1041-RLP
Pin, Road Lock
11
AR
SM-0933
Shim, 18 Ga. (.0478”) Driver
12
AR
SM-0934
Shim, 14 Ga. (.0747”) Driver
13
AR
SM-0935
Shim, 10 Ga. (.1345”) Driver
14
4
SM-0041-BR
Bumper, Rubber
15
2
SD-101-B2
Bushing, 1-7/8 OD x 5/8 ID x 2 L
16
1
300112
Washer, Lock 1" Zn
17
4
300101
Washer, Lock 1/2" Zn
18
2
300132
Screw, Cap 1/2-13 x 2 Hex Head Gr5 Zn Full Thread
19
2
300137
Bolt, Tap 1/2-13 x 4-1/2 Hex Head Gr5 Zn Full Thread
20
2
300115
Nut, Hex 7/16-14 Heavy Pattern Zn
21
2
300113
Bolt, Tap 7/16-14 x 2-1/2 Hex Head Gr5 Zn
22
2
300356
Nut, Cone 7/16-14 Lock Zn
23
2
300178
Washer, Flat 3/8” Zn
24
2
300181
Nut, Cone 3/8-16 Lock Zn
25
2
300184
Screw, Cap 3/8-16 x 1-1/2 Hex Head Gr5 Zn
26
4
300203
Nut, Hex 5/16-18 Zn
27
4
300204
Washer, Lock 5/16” Zn
