Technical specifications
7
Shell
RIDE
Motor: Rear-wheel hub motor with 250-watt capacity
Battery: 36 V / 8.0 Ah lithium ion
Charging time: Approx. 3.2 hours
Brakes: Front and rear disc brakes
Features: LED display, reflectors
Dead weight: 38.0 lbs. (17.2 kg)
Maximum load: 250 lbs. (113.4 kg)
Maximum speed: 16.0 mph (25.75 km/h)
Maximum range: TBD
Tires: 27.5” pneumatic tube tires front and rear
Product size: L-42.0” x H-36.75” (L-107 cm x H-93 cm)
