Control and charging functions
13
Shell
RIDE
Throttle:
The SR-3B is equipped with a throttle with an on/
off switch. Like on a motorcycle, throttles are de-
signed to let the user apply 0-100% of the motor’s
power at will. The throttle either acts independent-
ly, or in tandem with a pedal assist sensor.
Brakes:
The brakes on an electric bike are the same as on a normal bike, with one exception: most have
integrated cutoff switches which kill the motor when activated. These “inhibitor” switches are a safety
feature designed to prevent the motor from accidentally engaging and causing injury. If for any rea-
son you need the motor to stop turning, remember to simply squeeze one of the brake levers.
Battery Removal:
step 1: Insert the key to the battery.
Turn the key clockwise.
step 2: Grasp the battery with both hands and
slide up to remove for easy charging.
The battery is the power source of the bike and has it’s own on/off switch. To charge the battery,
remove the rubber cap on battery. Plug the charger into the power outlet and wait until the light on
the charging unit is illuminated. Plug the other end of the cord into the bike. The light will turn green
when it’s fully charged.
