ShelterLogic Round Top User Manual

Page 5
12’W x 8’H (or 10’H) RoundTop
®
Frame Assembly
Please read and understand instructions completely before assembly.
Layout out frame parts as shown and match up items
with quantity to make sure no parts are missing.
Assembly
Reference #
1
2
3
4
5
6
7
8
Mfg.
Part #
10224
10225
10226
10273
02030
02031
10110
10111
Assembly
Reference #
9
10
11
12
13
14
15
16
Mfg.
Part #
10112
10205
10270
00669
10210
10114
10115
800260
12'W x 8'H
ShelterLogic, LLC
150 Callender Road
Watertown, CT 06795
www.shelterlogic.com
Page 5
Page 4
05-201133_13-0D
05-201133_13-0D
12’W x 10’H (or 8’H) RoundTop
®
Frame Assembly
Please read and understand instructions completely before assembly.
Layout out frame parts as shown and match up items
with quantity to make sure no parts are missing.
ShelterLogic, LLC
150 Callender Road
Watertown, CT 06795
www.shelterlogic.com
ATTENTION:
FOR MISSING OR
REPLACEMENT PARTS
OR QUESTIONS, PLEASE
CONTACT
CUSTOMER SERVICE:
1.800.524.9970
CANADA 1.800.559.6175
Assembly
Reference #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Mfg.
Part #
10224
10225
10226
10273
10223
02030
02031
10205
10110
10111
10112
00669
10210
10114
10115
10270
800260
5
4
5
3
12'W x 10'H
ATTENTION:
FOR MISSING OR
REPLACEMENT PARTS
OR QUESTIONS, PLEASE
CONTACT
CUSTOMER SERVICE:
1.800.524.9970
CANADA 1.800.559.6175
END RIB
SIDE RAIL
TOP RAIL
MIDDLE RIBS
END RIB
WIND
BRACE
WIND
BRACE
COVER RAIL
END RIB
SIDE RAIL
TOP RAIL
MIDDLE RIBS
END RIB
WIND
BRACE
COVER RAIL
