Shenchen Pump LabV Series
a. In Pulse mode: Short circuited K2 then disconnect, the motor starts running.
Short circuited and disconnect again, motor stops running. (Under transferring
and dispensing modes, current working has been stopped. Under fixed volume
measurement mode, current working has been paused. Disconnect after short
circuit again, it will continue to work); In Level mode: Short circuited K2, the
motor starts running, disconnect K2, motor stops running.
b. In Pulse mode: Short circuited and then disconnect K1 once, the motor
changes working direction once. In Level mode: Short circuited K1, motor
runs in clockwise, disconnect K1, motor runs anticlockwise.
c. In Pulse mode: Short circuited K3 then disconnect, the motor starts running;
short circuited K3 and disconnect again, motor stops running. (Under
transferring and dispensing modes, current working has been stopped. Under
fixed volume measurement mode, current working has been paused.
Disconnect after short circuit again, it will continue to work); In Level mode:
short circuited K3, motor starts running, disconnect K3, motor stops running.
d. In Pulse mode: Short circuited K4, the motor will run with full speed;
Disconnect it, the motor stops.
