PARTS
DRA
WING AND LIST
Part
No. 820–337
Ref No. 74
Pressure Control Assembly
Includes replaceable items
listed below
NOTES:
Numbers with “Ref” preceeding
them correspond with the parts
list on page 20.
See wire colors in Fig 10.
Ref 81
116
Ref 77
72
Ref 22
111
SEE
INFORMA
TION
BELOW FOR WHICH
CIRCUIT BOARD T
O
USE
LABEL
Ref
79
Ref 78
114
Ref 105
107
Ref 122
Ref 93
LABEL
109
110
Ref 104
75
Ref 75
85
Ref 76
86
Ref 1
Ref 123
113
106
108
REF
NO. PART NO. DESCRIPTION QTY
71 820–319 T
AG, caution
see page 21
1
72 820–320
LABEL, caution
1
75 820–322 CONNECT
OR, conduit, 90
_ 1
85 820–341 BOOT, switch 1
86 820–342
SWITCH, toggle
1
106 820–527 BUSHING, strain relief 1
107 820–448 LOCKW
ASHER, int, No. 8
1
108 820–528 CORD SET 1
109 820–529 NUT
, hex, No. 6–32
2
110 820–530 LOCKWASHER, No. 6 2
111 820–531 SCREW
, mach, flat hd,
No. 6–32 x 5/8”
2
113 820–532 TRIAC 1
114 820–424 SCREW
, mach, pan hd,
No. 8–32 x 5/16”
1
116 178–797*
LABEL, warning
1
123 820–556
PLUG, pipe
1
*Extra warning labels available at no cost.
CIRCUIT
BOARD APPLICA
TIONS
Identify the correct circuit board for your sprayer by
matching the information below. The circuit boards
may
be
purchased separately
,
but all replacement motors for
this
sprayer include a new circuit board.
820–328 820–618
Circuit Board P/N
and style
used
in used in
820–002,
A,B,C & D
Sprayer
,
Series
820–002,
E & F
820–250 Sherwin William
Motor P/N
820–621
3/4 HP
Motor ID Label
3/4 HP+
112175402
Franklin Motor P/N,
Series
111
1006400, E
111
1006406, F
To Next Page
