INSPECTION AND MAINTENANCE
[Caution for Handling]
●
Check the oil level before starting the
engine or while the engine is cold.
●
To check the oil level, place the vehicle on
a horizontal place and check while the oil
surface is horizontal.
● Never discard waste
oil to a river or
sewage. Ask a professiona
l to discard the
waste
oil or take some other appropriate
means.
Exchange
Discharge the oil from the drain plug under the
engine. After the oil is completely discharged,
tighten the drain plug and fill with
new oil from
the oil filler port.
②
②②
② HS
HSHS
HST oil
T oilT oil
T oil
Check
Lower the implement and check the oil level
with the level gauge on the hydraulic tank (left
side). If the oil level is below the center on the
gauge, supply oil up to the specified level (1/2
to 2/3 of the level gauge) from the oil feeler
port.
Removing the Oil Breather Port Cap
Turn the breather counterclockwise to remove it.
After supplying oil, tighten the breather.
Exchange
Discharge the oil from the drain plug under the
hydraulic oil tank. The oil may be discharged
easily while the oil is still
warm. (Be careful for
hot oil.) After the oil is completely discharged,
tighten the drain plug and su
pply new oil from the
oil breather port.
Fig. 8-7
