SECTION 4 – SXM54, SXM60 MOWER DECK
4-11
2. Remove and re-install the four gauge wheels
① in the sideways position.
3. Secure the wheel spindles with the clevis
pins ② and clips ③.
CAUTION
When rolling the mower deck under the
tractor, be very careful not to strike the
hydraulic filter with the mower deck.
4. Roll the mower deck under the tractor and
position for connection to the lift linkage.
5. Place the mower height adjustment lever ①
in the 1" cutting height position.
6. Start the engine on the tractor.
7. Shift the 3 PT lever ② forward, to the
"lower" position.
8. Turn the engine off.
