1. BASIC OPERATION
1.1 Balance Components
Open the package and sure following items are included.
Balance body, pan, AC adaptor, Balance cover, adhesive tape,
Instruction manual, inspection certificate,
<BW-K only>
Internal weight, Fix screw of the internal weight, cover of the internal weight
Fix of the screw of the internal cover

[ Name ]
[ Appearance ]
[ Notes ]
Balance unit
Pan
Built-in calibration
mass
Calibration weight
stopper screw
Calibration weight
cover
Calibration weight
cover setscrew
A
C adapto
r
The serial number of the
balance is stated on this
nameplate
Check that the numerals on
this part are the same as the
last 5 figures of the serial
number on the balance unit
(BWK series only)
(BWK series only)
(BWK series only)
(BWK series only)
