INSTALLATION
 Mounting the pedals on the crank arms
1. Apply a small amount of grease to the thread to prevent sticking.
2. Use a 15 mm spanner to mount the pedals on the crank arms.
• The right pedal has a right-hand thread; the left pedal has a left-hand thread.
3. Remove any roughness or burrs on the joint, if detected.
15 mm spanner
Pay attention to the mark
R: right pedal
L: left pedal
Tightening torque:
35 - 55 N·m {306 - 480 in. lbs.}
