 Replacing and mounting the reflectors
A special reflector set SM-PD64 is available. Mount reflectors with pins.
Reflector
Pin
Tightening torque:
2 - 2.5 N·m {18 - 21 in. lbs.}
Note:
• When using the product without a reflector, adjust the protrusion of pins using attached spacers.
For details, refer to “Adjusting the gripping force”.
