31
SW-E6000/SC-E6010
A
X1
Y1
(A)
Clear settings
(B)
Clock setting
(C)
Turning the display backlight on/off
(D)
Display backlight brightness setting
(E)
Turning the beep noise on/off
(F)
Switching between km and miles
(G)
Language setting
(H)
Changing the font color
(I)
Adjusting the electronic gear shifting unit
(J)
Activating RD Protection Reset*
(K)
Return to the main screen
[Start mode] and [Auto] are displayed on the menu list
screen; however, they are not available for use.
SC-E6010
(A) Clear Exit (K)
(B) Clock
RD protection
reset
(J)
(C) Backlight
(D) Brightness Adjust (I)
(E) Beep Font color (H)
(F) Unit Language (G)
*
In order to protect the system from falling down
etc., if the bicycle is subjected to a strong impact,
the RD Protection function will operate and the
connection between the motor and the link will be
momentarily severed so that the rear derailleur can
no longer operate. Executing RD Protection Reset
restores the connection between the motor and the
link, as well as the function of the rear derailleur.
To Next Page
