Shire Command post - Page 31

17
I Nail the fascia boards into position and carefully trim the excess felt .
Position the cover strips “A0570” over the panel join and mark and trim to fit under the fascia boards.
Attach with 3x 40mm nails each.
GB-IE
A0570
A0570
Cover strip
(A0570) x02
44mm
40mm Nail2
(A0025)x18
Fascia
(A0576) x02
31
