Shop fox M1049 - Steady Rest; Follow Rest

-53-
D('+09\eZ_kfgCXk_\D]^%J`eZ\/&'0
G8IKJ
Steady Rest Follow Rest
501A
501
502
503
504
505
505
506
507
508
509
551A
551
552
553
554
555
556
557
558
REF PART # DESCRIPTION
501A XM1049501A STEADY REST ASSEMBLY
501 XM1049501 STEADY REST BODY
502 XM1049502 STEADY REST FINGER
503 XM1049503 STEPPED T-BOLT
504 XPLW04M LOCK WASHER 8MM
505 XPN03M HEX NUT M8-1.25
506 XM1049506 ADJUSTMENT SCREW
507 XM1049507 CLAMPING PLATE
508 XPB28M HEX BOLT M8-1.25 X 60
509 XPW01M FLAT WASHER 8MM
REF PART # DESCRIPTION
551A XM1049551A FOLLOW REST ASSEMBLY
551 XM1049551 FOLLOW REST BODY
552 XM1049502 FOLLOW REST FINGER
553 XM1049503 STEPPED T-BOLT
554 XM1049506 ADJUSTMENT SCREW
555 XPN03M HEX NUT M8-1.25
556 XPW01M FLAT WASHER 8MM
557 XPCAP07M CAP SCREW M6-1 X 30
558 XPW03M FLAT WASHER 6MM
