Shure E2c User Guide

ENGLISH
8
4. Make sure that the tip of the nozzle is dry, then remove a wax guard from the supplied
strip and place it on the tip of the nozzle, adhesive side down.
5. Place the sleeve on the earphone.
WAX GUARD
FOAM SLEEVE
NOZZLE
FIGURE 2: E2c Wax Guard Installation
IMPORTANT: Do not place Wax Guards on sleeves! Wax guards are
intended for use on the tip of the earphone only, otherwise they will not
function properly.
SPECIFICATIONS
E1c E2c E5c
Transducer Type
Low mass/
high energy
Dynamic
Dual low mass/
high energy
Sensitivity (at 1kHz)
113.5 dB
SPL/mW
105 dB
SPL/mW
122 dB
SPL/mW
Impedance (at 1kHz)
29Ω 16Ω 110Ω
Output Connector
Gold-plated, 3.5 mm (
1
/
8
in.), stereo plug
Cable Length
1.52 m
(60 inches)
1.57m
(62 inches)
1.55 m
(61 inches)
Net Weight
17 g (0.6 oz) 30 g (1 oz) 31 g (1.1 oz)
