Shure LX1 Service Manual

Shure LX4 Diversity Receiver
24
Replacement Parts and Drawings
25D1008 (BK)
Table 4
Printed Circuit Board Components
Reference Designation Description
Shure Part
Number
D9,10,18 Surface mount LED, orange 184E18
D11,12,13,14,15,16,19,
20,21,22,23,24,25,26
Surface mount LED, green 184D18
D17 Surface mount LED, red 184A18
J1 Output XLR connector, male 95A8598
J2 Shrouded header 95A8272
J3 1/4 inch phone jack 95A8104
J100,200 Antenna connector 95X8414
L100,101,104,105,112,
113,200,201,204,205
Tunable coil 82A8003
L108,208 Tunable coil 82A8005
L110,210 Quadrature coil 82A8004
L111,114 Tunable coil 82B8003
R32 Potentiometer 46A8032
R66 Potentiometer 46B8055
R58,59,60,130,230 Potentiometer 146D02
S1 Switch, DPDT 55A8061
S2 Switch, power 55B8062
Q1 Transistor 183A38
U9 Compander 188A01
U3,4 Comparator 188A123
U100,200 Detector 188A129
U5 Op Amp 188A150
U6 Switch 188A19
U1,2 Op Amp 188A49
U10,11,12 Driver 188A86
Q100,101,200,201 Amp 183A12
Q103,104 Transistor 183A14
Voltage regulator 86A8918
