Shure Incorporated
26/36
Total Harmonic Distortion
ref. ±34 kHz deviation @1 kHz
<0.5% (typical)
Companding
Patented Shure Audio Reference Companding
Spurious Rejection
ref. 12dB SINAD
>80 dB (typical)
Latency
<0.7 ms
Frequency Stability
±2.5 ppm
MPX Pilot Tone
19 kHz (±1 Hz)
Modulation
FM*, MPX Stereo
*ref. ±34 kHz deviation @1 kHz
Operating Temperature
-18°C to +63°C
RF Output Power
10, 20, 30 mW
Note: varies by region
RF Output Impedance
50 Ω (typical)
Net Weight
783 g(27.6 oz.)
Dimensions
43 x 198 x 172 mm (1.7 x 7.8 x 6.8 in.), H x W x D
Power Requirement
12-15V DC, 260 mA Maximum
Audio Input
Connector Type
6.35 mm (1/4") TRS
