System Overview
This example shows a typical setup for musical performance. See the System Applications section for additional examples.
① Route audio signals Send Instrument and microphone signals from the stage to a mixer or PA system.
② Create monitor mixes
From the mixer, create two mixes: one of just the instruments, and a second with just the vo
cals. Route each of these to separate mixer outputs and connect them to the P3T inputs.
