25 kHz, varies by region
Image Rejection
>70 dB, typical
RF Sensitivity
-97 dBm at 10-5 BER
Latency
<2.9 ms
Audio Frequency Response
QLXD1 20 – 20 kHz (±1 dB)
QLXD2 Note: Dependent on microphone type
Audio Dynamic Range
System Gain @ +10
>120 dB, A-weighted, typical
Total Harmonic Distortion
−12 dBFS input, System Gain @ +10
<0.1%
System Audio Polarity
Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3
of XLR output) and the tip of the 6.35 mm (1/4-inch) output.
Operating Temperature Range
-18°C (0°F) to 50°C (122°F)
Note: Battery characteristics may limit this range.
Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Note: Battery characteristics may limit this range.
Battery Life
QLXD SB900A alkaline
1/10 mW 1/10 mW
470 to 865 >9:30 hours 8 hours
902 to 928 >8:30 hours >6 hours
174 to 216 >9:30 hours >8:30 hours
1240 to 1800 >8:00 hours >6 hours
The values in this table are typical of fresh, high quality batteries. Battery runtime varies depending on the
manufacturer and age of the battery.
QLXD4
