SLX 수신기 선반 장착
하나의 수신기
• 모든액세서리가제공됨
보호 범퍼 달기
수신기가랙에장착되지않을경우권장.제공된나사를사용하십시오.
SLX4 Receiver
두 개의 수신기
• 필요한 액세서리: 1 x UA440
UA221 안테나 분배기/병합기 (Splitter/Combiner) 키트를
사용한 두 개의 수신기
• 필요한 액세서리: 1 x UA221
세 개 또는 네 개의 수신기
• 필요한 액세서리: 1 x UA844
23
