Shure SLX Specifications

2
SLX WIRELESS SYSTEM SPECIFICATIONS
SPECIFICATIONS
System
Frequency Range and Transmitter Output Level
NOTE: This Radio apparatus may be capable of operating on some
frequencies not authorized in your region. Please contact your national
authority to obtain information on authorized frequencies for wireless
microphone products in your region.
Operating Range Under Typical Conditions
100m (300 ft.)
Note: actual range depends on RF signal absorption, reflection, and
interference
Audio Frequency Response (+/– 2 dB)
Minimum: 45 Hz
Maximum: 15 kHz
Total Harmonic Distortion (ref. +/– 38 kHz deviation, 1 kHz tone)
0.5%, typical
Signal-to-Noise Ratio
>100 dB A-weighted
Operating Temperature Range
–18°C (0°F) to +50°C (+122°F)
Note: battery characteristics may limit this range
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage applied
to tip of WA302 phone plug) produces positive voltage on pin 2 (with
respect to pin 3 of low impedance output) and the tip of the high
impedance 1/4-inch output.
SLX1 Bodypack Transmitter
Audio Input Level
+10 dBV maximum at 0 dB gain position
Dimensions
108 mm H x 64 mm W x 19 mm D (4.25 x 2.50 x 0.75 in.)
Weight
81 grams (3 oz.) without batteries
Housing
Molded ABS case
Power
2 “AA” size alkaline or rechargeable batteries
Battery Life
>8 hours (alkaline)
SLX2 Handheld Transmitter
Audio Input Level
+2 dBV maximum at minimum gain position
Dimensions (including SM58 cartridge)
254 mm x 51 mm dia. (10 x 2 in.)
Weight
290 grams (10.2 oz.) without batteries
Housing
Molded PC/ABS handle and battery cup
Power
2 “AA” size alkaline or rechargeable batteries
Battery Life
>8 hours (alkaline)
SLX4 Receiver
Dimensions
42 mm H x 197 mm W x 134 mm D (1.65 x 7.76 x 5.28 in.)
Weight
816 g (1 lb. 13 oz.)
Housing
Galvanized steel
Audio Output Level (ref. +/– 38 kHz deviation with 1 kHz tone)
XLR connector (into 600 ohm load): –13 dBV
1/4 inch connector (into 3000 ohm load): –2 dBV
Output Impedance
XLR connector: 200 ohms
1/4 inch connector: 1kohm
XLR output
Impedance balanced
Pin 1: Ground
Pin 2: (+)
Pin 3: (-)
Sensitivity
–105 dBm for 12 dB SINAD, typical
Image Rejection
>70 dB, typical
Power
12–18 Vdc at 150 mA, supplied by external power supply
Band Range Transmitter output
H5
518–542 MHz 30 mW/15 dBm
J3
572–596 MHz 30 mW/15 dBm
L4
638–662 MHz 30 mW/15 dBm
P4
702–726 MHz 30 mW/15 dBm
R5
800–820 MHz 20 mW/13 dBm
S6
838–865 MHz 10 mW/10 dBm
JB
806–810 MHz 10 mW/10 dBm
Q4
740–752 MHz 10 mW/10 dBm

Shure SLX Specifications

General

Operating Range	100 m (300 ft), typical
Dynamic Range	>100 dB
Total Harmonic Distortion	<0.5%, typical
RF Output Power	10 mW (region dependent)
Receiver Outputs	XLR and 1/4"
Transmitter Type	Handheld or Bodypack
Microphone Capsule (Handheld)	Shure SM58 or Beta 58A (depending on model)
Power Supply	Transmitter: Batteries
Modulation	FM
Signal-to-Noise Ratio	>100 dB
Weight (Transmitter)	Handheld: 290 g
Frequency Range	470-952 MHz (region dependent)
