Replacement Parts and Drawings
Table 8
Network Interface Printed Circuit Board Replacement Parts,
Non-SMT Components, Side 1
Reference Designation Description Shure Part Number
P201, 202 Header, dual row 95A8660
P203 Header, single row, 5 position 95A8659
Table 9
Monitor Printed Circuit Board Replacement Parts,
SMT Components, Side 1
Reference Designation Description Shure Part Number
U201, 202, 204, 205, 207 Dual Op Amp 188A18
Table 10
RF–Audio Printed Circuit Board Replacement Parts,
Non–SMT Components, Side 1
Reference Designation Description Shure Part Number
C238 Electrolytic capacitor, 10 µF x 80 V 86AS629
C243, 247 Electrolytic capacitor, 47 µF x 63 V 86BE629
FL301, 305, 306, 307, 308, 309,
319, 320
Ceramic filter 86A8971
FL304, 312 Saw filter 80A8195
J203, 216 Header, 6 pin 95A8363
J209 Phone jack, 1/4–inch 95Z8322
J211 XLR connector, male 95A8400
J301, 302, 303, 304 Jack, mini pin 95A8278
L302 Coil, tunable 82A8026
L304, 310 Coil, quadrature (For PCB versions 34A8507) 82A8004
FL311, FL313 Coil, quadrature (For PCB versions 34A8703) 82A8004
L313, 324 Coil, tunable 82A8025
P201, 202 Header, dual row 95A8660
P203 Header, single row, 5 position 95A8659
R203, 250, 265, 531 SMD trim potentiometer, 1k 146B02
R355, 367 SMD trim potentiometer, 5k 146D02
S201 Switch, slide 55A8087
S202 Switch, slide, DPDT, right angle 55A8061
Y201 Crystal, tone key, 32.76 kHz 40A8010
Y301 Crystal, leaded, 60.7 MHz 40A8013
