Shuttle HOT-603 - CPU Voltage Configuration - JPW!, JV2, JV3 and JV4

10
Voltage
CPU Type
Jumper-Setting
Type Vcore Vio JPW1 JV3 JV4 JV2
Single
3.52V 3.52V
3.52V AMD K5 ABx,
Pentium P54C VRE,
Cyrix/IBM 6x86
3.3V 3.3V
Pentium P54C STD,
Cyrix/IBM 6x86
Dual
3.2V 3.3V
AMD-K6
233 / 266 MHz
2.9V 3.3V
AMD-K6
166 / 200 MHz,
Cyrix 6x86MX
2.8V 3.3V
Pentium P55C
MMX,
Cyrix 6x86L
2.1V 3.3V
AMD-K6
266 / 300 MHz
CPU Voltage Configuration - JPW1, JV2, JV3 and JV4
Table 2-4
3.45V
3.3V
