KBC Input Clock
This item specifies onboard keyboard controller clock input. default is 8 MHz.
Onboard FDC Control
This item specifies onboard floppy disk drive controller. This setting allows you to
connect your floppy disk drives to the onboard floppy connector. Choose the "Disabled"
settings if you have a separate control card.
Onboard Serial Port 1/2
This item is used to define onboard serial port 1/Port2 to 3F8/IRQ4, 2F8/IRQ3, 3E8/
IRQ4, 2E8/IRQ3, Auto or Disabled.
Onboard Parallel Port
This item specifies onboard parallel port address to 378H, 278H, 3BCH or Disabled.
Parallel Port Mode
This item specifies onboard parallel port mode. The options are SPP (Standard Parallel
Port), EPP(Enhanced Parallel Port), ECP (Extended Capabilities Port), and EPP+ECP.
ECP Mode Use DMA
This item specifies DMA (Direct Memory Access) channel when ECP device is in use.
The options are DMA 1 and DMA 3. This item will not show up when SPP and EPP
printer mode is selected.
Onboard IR Controller
The main board support IrDA(HPSIR) and Amplitudes Shift Keyed IR(ASKIR) infrared
through COM 2 port. This item specifies onboard Infra Red mode to IrDA 1.0, ASKIR,
MIR 0.57M, MIR 1.15M, FIR or Standard (Disabled).
Note : FIR is not available currently.
Phone Ring wake Up
This item determine the system will resume by activating of modem ring.
RTC Power On Controller
(This feature is available for ATX power only)
This item determine the system will resume by activity of R.T.C. If enabled this feature
and enter resume date and time. When date and time expire, system will power-on itself
from power off.
Listed five items will shown up when enabled "RTC Power On Controller" .
RTC Power On (Yeat Ctrl)
This item determine the year when system will resume from power-off.
RTC Power On (Month Ctrl)
This item determine the month when system will resume from power-off.
