3. Knowing the products
3.1 Product description
Figure 3.1: FS8001 / FS8001N description
Figure 3.2: FS8003P description
Direction for flow
measurement.
Threaded outlet,
inlet at the opposite
Installation hole
Power and data
connector.
Power and data
connector.
Threaded inlet
Installation thread
Flow direction
Threaded outlet
