Sic Marking i124s - Marking Head Origin Issues; Marking Quality Problems

NOTI124SUS-R01.docx Translation of the original instructions 12/19
3Rd CASE: THE MARKING HEAD DOES NOT GO BACK HOME (ORIGIN)?
1) Is the sensor out of order?
Change the sensor.
2) Is the belt broken?
Change the belt.
3) Is the engine out of order?
Change the engine
4) You have checked everything and it still does not work?
Call our After Sales Service.
MARKING PROBLEMS
- IF THE MARKING QUALITY DETERIORATES, CHECK THE FOLLOWING:
 Part is clamped or properly
fastened
- Replace the part properly
 Distance part/pin
- Adjust the distance (See manual)
 Solenoid cable is cut
- Check the cable and change it
 Correct speed
- Change the speed (See manual)
 Is the column tight
- Tighten the column locking system.
 Damaged pin?
- Check the pin
 The marking head moves
- Check that the marking head bolts are
tightened by removing the housing
 Play in X or Y axis
- Inform our After Sales Service
