Please be sure that the power supply is grounded.
Connect to the controller the different elements by plugging in the connectors at the rear face
of the controller.
The PC will not be used for most application so you don’t need to connect it if the machine is
running in stand alone mode. Otherwise, use the HOST port for such connection.
Connect the marking head to the compressed air system (6 bars maximum) with a 6 mm
diameter hose.
NEVER UNPLUG THE CONTROLLER WHEN THE POWER IS ON
AS IT MAY SERIOUSLY DETERIORATE THE
EQUIPMENT.
c) Software
Consult the manual of the related software.
IV – USE OF THE MACHINE
1/ SAFETY
Machine integration must protect user
from head and piston movement
(50 DaN)
It is recommended to wear safety
glasses.
IMPORTANT :
Acoustic value of the machine: 70 dB on a piece of steel at medium speed
