Sices DST4600A - Starting Battery Fault; Minimum Fuel Level Alarm; Maximum Fuel Level Alarm

User’s Manual 17
Disabling
Bit 7 of the Parameter P49 = 0
Conditions for its
activation
Starting not in progress (output “START”, terminal 20 not
enabled)
Battery voltage under 11.8 (or 23.2) V or battery voltage over
15 (or 30) V
Filter time
40 seconds
Visual signal
Slow flashing of the indicator “DISCHARGED”
Disabling
Bit 6 of the Parameter P39 = 0
Conditions for its
activation
Digital input “LOW LEVEL FUEL” (terminal 05) shorted to
ground
Filter time
2 seconds
Visual signal
Slow flashing of the indicator “MIN LEVEL”
Disabling
Parameter P48 =0 and/or parameter P33 = 0
Conditions for its
activation
Level detected from the analogue input “FUEL LEVEL”
(terminal 45) under or equal to the threshold set through the
parameters P33
Filter time
2 seconds
Visual signal
Slow flashing of the indicator “MIN LEVEL”
Disabling
Bit 6 of the parameter P39 = 0
Conditions for its
activation
Digital input “HIGH LEVEL FUEL” (terminal 04) shorted to
ground
Filter time
2 seconds
Visual signal
Slow flashing of the indicator “MAX LEVEL”
Disabling
Parameter P48 =0 and/or parameter P27 = max
Conditions for its
activation
Level detected from the “FUEL LEVEL” analogue input
(terminal 45) over or equal to the threshold set through the
parameter P27
Filter time
2 seconds
Visual signal
Indicator “MAX LEVEL” slowly flashing
