14 DST4602Evolution User’s Manual
Enable the mode with the ENTER button.
Use the UP and DOWN buttons to select a menu and the ENTER button to open the
same. Select the variable or submenu with the UP and DOWN .buttons.
Pressing ENTER when there are no submenus, displays the page of variables for the menu entry.
The value of the variable is displayed in square brackets, for example: [400]
To change the variable, press ENTER ; the square brackets [ ] will flash. Use the
UP and DOWN buttons to change the value and press ENTER to confirm or EXIT
to abort.
To change the variables, the lockable selector must be OFF. Some variables can only be changed with the
lockable selector in another position other than OFF.
If you cannot change a variable in any condition, this is shown as follows:<400> showing that the parameter
cannot be changed in this status.
To exit the programming menu, use the EXIT button.
For some parameters you will have to set a value for the string data.
In this case, pressing ENTER makes the square brackets [ ] around the variable flash, and a cursor
appears under the first character of the string. Using the LEFT and RIGHT buttons, you can select
which character to change. Then, use the UP and DOWN buttons to change the character
selected. Repeat the procedure for each character that needs changing.
Use ENTER (confirm) or EXIT (abort) to end the procedure.
