Mechanical data
T
able 8: Mechanical data
Weight 130g
Mounting Mounting rail (IEC60715)
Connection type Spring terminals
Stripping length 8mm
Wire cross-section
Single wire (1×) 0.14mm
2
…1.5mm
2
Fine wire (1×) 0.14mm
2
…1.5mm
2
Fine wire with ferrules (2 ×, same cross-sec‐
t
ion) with TWIN ferrule with plastic collar
≤0.5mm
2
Fine wire with ferrules with or without collar
(1×)
0.25mm
2
… 1.0mm
2
For UL and CSA applications 26AWG … 14AWG
Use c
opper conductors only min. rated for
85°C.
Electrical data
T
able 9: Operating data
Supply voltage V
S
24VDC (16.8VDC … 30VDC) (safety extra-
lo
w voltage)
1)

Rated voltage +24VDC
Residual ripple U
ss
2.4V
Power consumption ≤1.3W
≤
2.5W from hardware version 2.00.0
Short-circuit protection Max. 4A
S
afety fuse with triggering characteristic: slow-
blow
UL/CSA applications: UL-listed fuse according
to UL248-14 required
Power-up delay after supply voltage applied ≤5s
1)
The external voltage supply must be capable of bridging a brief power failure of 20ms as specified in
IE
C60204-1. Suitable power supply units are available as accessories from SICK.
Protect supply voltage against short-circuit.
Table 10: Inputs (I1, I2, I3, I4, S1)
Input voltage HIGH 24VDC (11VDC … 30VDC)
Input voltage LOW 0VDC (–3VDC … 5VDC)
Input capacitance ≤15nF
Input current 4mA … 6mA
Reset time 80ms … 250ms
Synchronization time (between the actuators) 500ms (475ms … 525ms)
Length of cable (single) ≤100m
