Table 11: Application diagnostic output (Y1)
Type of output
•
PNP semiconductor output, short-circuit
protected
•
Push-pull semiconductor output, short-cir‐
cuit protected, from hardware version
2.00.0
Output voltage HIGH (U
V
– 3V
) … U
V
Output voltage LOW 0V … 3V hardware version 2.00.0 and above
Input current (NPN) ≤15mA hardware version 2.00.0 and above
Output current (PNP) ≤120mA
Table 12: Enabling current path (13/14, 23/24)
Response time (opening of enabling current paths) ≤10ms
Number of enabling current paths (normally open,
s
afe)
2
Contact type Positively guided
Contact material Silver alloy, gold flash plated
Switching voltage
At altitudes below 2,000m above sea level 10VDC … 250VDC
10VA
C … 250VAC
At altitudes 2,000m above sea level … 4,000m
abo
ve sea level
10VDC … 150VDC
10VAC … 150VAC
Switching current 10mA … 6A
see
figure 11, page 29
see figure 12, page 30
Sum current ≤12A
Utilization category AC-15: 230V, 5A (IEC 60947-5-1)
DC
-13 (0.1Hz): 24V, 4A (IEC
60947-5-1)
DC switching capacity 0.1W … 200W
see
figure 11, page 29
AC switching capacity 0.1VA … 1,500VA
Switching frequency ≤1Hz
Mechanical service life 10×10
6
s
witching operations
Contact fuse with safety fuse gG or circuit breaker C Max. 6A
Max. short-circuit protection ≤400A
Table 13: Insulation coordination – enabling current paths (13/14, 23/24) to the 24V circuit
Type of insulation (IEC60947-1) Safe electrical separation
Degree of contamination 2
Air and creepage distances between the insu‐
la
ted circuits
≥5.5mm
Rated insulation voltage
At altitudes up to 2,000m above sea level 250VAC
At altitudes up to 2,000m abovesea level …
4,000m abo
ve sea level
150VAC with overvoltage category III
250VAC with overvoltage category II
Rated impulse withstand voltage U
im
p
