NOTE
It is not possible to connect a digital output on pin 2.
Rest:
Through the “Rest Out” block, data from the logic can be sent via REST interface to an upper system (e. g. HTTP
Client).
Logics:
Table 24: Logic blocks
Description Addition of the two input values.
Number of inputs 2
Input data type Integer
Input description num1: first input value
num2: second input value
Number of outputs 1
Output data type Output 1 (“+“): Identical to input data type
Output description result: result after addition of the two input values
Settings no settings available
8 DEVICE FUNCTIONS
80
O P E R A T I N G I N S T R U C T I O N | Sensor Integration Gateway - SIG200 8024482.1FJ7 /2022-05-31 | SICK
Subject to change without notice
