Sicma S.p.A.
Miglianico (CH)
page 27
FEELER AND SPRING-LOADED ARMS MAINTENANCE
FIRST CHECK
- After the first 50 hours of work change oil in
oil tank A (picture 28)*
EVERY 8 HOURS OF WORK
- Grease all components of the arm through
lubricating nipples A (pictures 29 and 30)
EVERY 50 HOURS OF WORK
- Check oil level in tank A (picture 28) through
plug B.
EVERY 500 HOURS OF WORK
- Replace oil filter C (picture 28) *
- Change oil in oil tank *
ATTENTION: this maintenance activity is to be made only at SICMA authorized repair shops.
Get rid of exhaust oil in compliance with the relevant rules of
the country where you operate. It is thus forbidden to pour it
on the ground.
Before executing maintenance activities on the machine, stop
engine, disengage power takeoff, pull parking brake and
place the equipment on the ground.
28
30
