Siel Green Point - Appendix 3. Specification; Dimension & weight


IV394E Rev. 00
Installation and user manual
Date of issue: 2015-12-11
Pag. 31 di 34 + FR

Dynamic respond
5.0%
20ms
DC heft
ŏ
500mV
Switch time
Between Normal mode
and battery mode
0ms
Between inverter and
bypass
0ms
Ⱦ
unlock
φψ
15ms (50Hz),
ψ
13.33ms (60Hz)
Noise
<55dB
δ
1m
ε
Display
LCD+LED
Safety
Meeting IEC62040-1 GB4943
Ⱦ
Max input voltage
320Vac
θ
1Hr
EMI
Conduction
φ
IEC 62040-2
Radiation
φ
IEC 62040-2
Harmonics
φ
IEC 62040-2
EMS
IEC 62040-2
MTBF
250,000Hr 1
η
1 400,000Hr
MTTR
30min
Isolation resistance
> 2MΩ
δ
500Vdc
ε
Isolation intension
2820Vdc
θ
<3.5mA
θ
1min
Surge
Meeting IEC60664-1 1.2/50uS+8/20uS 6kV/3kA.
Protection
IP20
Parallel circumfluence
1
η
1≤8%
θ
N
η
1≤3%
Parallel equal current
1
η
1≤8%
θ
N
η
1≤10%
Dimension & weight
DIMENSION
Capacity
KVA
6KVA/5.4KW 10KVA/9KW
Height
mm
616
Width
mm
250
Depth
mm
502
Net weight
kg
6KVA
φ
62 Kg
10KVA
φ
75 Kg
Color
Blackness
