2 x 19 mm A/F spanner
Adjustable torque wrench in range 40 Nm to 70 Nm with 18 mm, 19 mm and 24 mm A/F sockets
Flat No.2 screwdriver
Flat No. 1 screwdriver
Cable stripping and lugging tools
5.2.2 Additional Parts
Earth cables and lugs
5.2.3 Mechanical Installation
A responsible person (or supervisor) must be assigned to oversee the installation and commissioning
work who instructs personnel during installation and commissioning tasks and checks for compliance
with the applicable safety measures. Furthermore, this person is responsible for the organization,
monitoring and signing off of the work.
The installation and commissioning work must be performed by authorised personnel with sufficient
qualifications and experience. Suitable lifting gear in good working order must be used for
installation.
Applicable accident prevention regulations must be observed.
5.3 RCU Mounting
The RCU is intended to be pole mounted onto timber, steel, concrete and stobie poles. The standard
RCU mounting bracket can accommodate all these options through the use of either bolting or
strapping of the bracket to the pole. A combination of one bolt and a strap is also acceptable so long
as the upper restraint is bolted.
Weight of RCU is approximately 15 kg (33 lbs), handle with
caution. Use safe lifting procedures.
The recommended installation sequence is:
1 Mount the bracket to the pole using either M16 galvanised bolts of grade 4.6 or higher
(torque 70 Nm) or straps taking into account orientation guidelines described in section
5.6.
2 Hang the cubicle over the bracket using the locating ears as a guide.
3 Fit the M12 cross-bolt and secure the RCU to the pole bracket (torque 40 Nm)
4 Connect earthing wire as required in section 5.10.
