CP 343-1 Lean
Equipment Manual, 01/2023, C79000−G8976−C198−09
17
Performance data
2.1 Transmission and reaction times
Measured values on the Internet
Measured values of transmission and reaction times over Ethernet, PROFIBUS and PROFINET
networks for
a series of configurations can be found on the Internet at the following address:
Link: (http://www.siemens.com/automation/pd)
2.2 Number of possible Ethernet/PROFINET connections
Maximum number of parallel connections
Table 2- 1 Maximum number of parallel connections
Permitted number of simultaneous connections in
total over Industrial Ethernet
Example of maximum load
You can, for example, operate:
• 4 S7 connections
• 4 ISO-on-TCP connections
• 2 TCP connections
• 2 UDP connections
