7XR6004 English
C53000-B119U-C137-1 7
Dimensions
Housing for panel flush mounting or cubicle installation (Size
1
/
2
)
Figure 1 Dimensions 7XR6004 for panel flush mounting or cubicle installation (size
1
/
2
)
Note: 2 set–squares (order–no. C73165–A63–C200–3) are required for installation in
cubicles.
225
220
255.8
± 0.3
245
+ 1
6
Side view (with screwed terminals)
Rear view
Panel cut-out
266
29.5 172 34
Mounting plate
180
± 0.5
206.5
± 0.3
13.2
7.3
5.4
244
221
+ 2
5 or M4
Dimensions in mm
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
10
11
12
B
A
