English 7XR6004
12 C53000-B119U-C137-1
Technical Data
Nominal power ratings
20 kΩ–power resistors P
70
= 45 W
3,3 kΩ test resistor P
70
= 7.5 W
Max. power dissipation
of one 20 kΩ power resistor when mounted in in the device
– if 2 resistors are used in the device 9 W, continously
corresponding to a voltage of 425 V at the terminals of the resistor
– if 4 resistors are used in the device 4,5 W, continously
corresponding to a voltage of 300 V at the terminals of the resistor
– short time overload four times the power continous rating
up to 10 s
– dynamic overload 900 W up to 10 ms
Insulation Tests
– High Voltage Test (routine test) 5 kV (rms), AC
– Impulse Voltage Test (type test) 10 kV (peak); 1,2/50 µs; 0,5 Ws; 3 positive
und 3 negative surges in intervals of 5 s
Temperatures
– recommended temperature during service –5 °C to +55 °C or +23 °F to +131 °F
– limiting, stand-by mode
operating temperature –20 °C to +70 °C or –4 °F to +158 °F
– limit temperature during storage –25 °C to +55 °C or –13 °F to +131 °F
– limit temperature during transport –25 °C to +70 °C or –13 °F to +158 °F
Storage and transport with standard works packaging!
Degree of Protection according to IEC 60 529
– for the device IP 20
– for touch protection IP 2x with fixed cover
