English 7XT3300-0*A00/DD
12 C53000-B119U-C129-1
Control module C53207-A332-B2- of 7XT3300-0*A00/DD
Figure 4 Control module with location of the jumper
S1
H102 H103
X 401
X 402
88 V ( Default setting )
19 V
X 403
STBG
C53207-A332-B2-
