Dimensions
7XT33 Housing for Surface Mounting Version
Figure 5 Dimensions of 7XT33 surface mounting version
209.5 (8.23) 34 (1.34)
266 (10 .47)
24 4 (9 .60)
Side View
Mounting Holes of
Mounting Plate
Rear View
200 ±0 .3 (7.87 ±0 .01)
12 .5
(0.49)
6.4
(0.25)
300 ±0.3 (11.81 ±0.01)
225 (8 .86 )
220 (8 .66 )
100 ±0 .3
(3.93 ±0.01)
3 12 .8 (1 2.2 8)
Ø4 .5 (0 .16) or M 5
RUN ERROR
Mounting Plate
Dimensions in mm
Values in Brackets in Inches
