Siemens 7XT3300-0 A00/DD Series User Manual

7XT3300-0*A00/DD English
C53000-B119U-C129-1 19
Electrical Tests
Specifications
Insulation tests
EMC tests for immunity (type tests)
Standards IEC 60255 (product standards)
IEEE Std C37.90.0/.1/.2
VDE 0435
For more standards, see individual tests.
Standards IEC 60255-5 and IEC 60870-2-1
High-Voltage Test (routine test) DC 3.5 kV
Impulse Voltage Test (type test)
all circuits, Class III
5 kV (peak value); 1.2/50 μs; 0.5 J;
3 positive and 3 negative pulses at intervals
of 5 s
Standards IEC 60255-6 and -22, (product standards)
EN 61000-6-2 (basic specification)
VDE 0435 Part 301DIN VDE 0435-110
High-Frequency Test
IEC 60255-22-1, Class III
and VDE 0435 Part 303, Class III
2.5 kV (peak value); 1 MHz; τ = 15 μs;
400 pulses per s; test duration 2 s; R
i
= 200 Ω
Electrostatic Discharge
IEC 60255-22-2, Class IV
and IEC 61000-4-2, Class IV
8 kV contact discharge; 15 kV air discharge;
both polarities; 150 pF; R
i
= 330 Ω
Irradiation with HF Field, Frequency Sweep
IEC 60255-22-3, Class III
IEC 61000-4-3, Class III
10 V/m; 80 MHz to 1000 MHz; 80 % AM;
1 kHz
10 V/m; 800 MHz to 960 MHz; 80 % AM;
1kHz
10 V/m; 1.4 GHz to 2.7 GHz; 80 % AM; 1 kHz
Irradation with HF Field, Single Frequencies
IEC 60255-22-3, IEC 61000-4-3, Class III
- amplitude-modulated
- pulse-modulated
10 V/m
80; 160; 450; 900 MHz; 80 % AM; 1kHz;
closing time > 10 s
900 MHz; 50 % PM, repetition frequency
200 Hz
Fast Transient Disturbance Variables /
Burst IEC 60255-22-4 and IEC 61000-4-4,
Class IV
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms;
repetition rate 300 ms; both polarities;
R
i
= 50 Ω; test duration 1 min
