English 7XT3300-0*A00
38 C53000-B1175-C129-1
7XT33 Housing for Panel Flush Mounting or Cubicle Installation
Figure 6 Dimensions of 7XT33 panel flush mounting or cubical installation
resp.
Ø6 (0.24)
172 (6.77 )
29 .5
(1 .16 )
34
(1.34)
266 (10 .47 )
24 4 (9 .60 )
Side View
resp.
Ø5 (0.20) or M4
Panel cut-out
Front View
180 ± 0.5 (7.09 ± 0 .02 )
7.3
(0.29)
13 .2
(0 .52 )
5 ,4 24 5 + 1 (9. 65 + 0.0 4)
2 55.8 ± 0 .3 (1 0.0 7 ± 0 .01 )
221 + 2 (8.70 + 0 .08 )
220 (8.66 )
225 (8.86 )
206 .5 ± 0. 3 (8. 13 ± 0 .01 )
Mounting Plate
BLOCKED RUN
Dimensions in mm
Values in Brackets in Inches
